• Trovac Tangential Electro-Motor, 240V with Wires (3.2 in.)
1 1

Trovac

Trovac Tangential Electro-Motor, 240V with Wires (3.2 in.)

Trovac Tangential Electro-Motor, 240V with Wires (3.2 in.)

$188.99 USD
$188.99 USD
Sale Sold out
Shipping calculated at checkout.

FMCY034301
Authorized Trovac Dealer Factory warranty, extended free where we can
Free Shipping On Eligible Orders $100+
Secure Checkout SSL Encrypted

Shipping Information

We offer free standard shipping on eligible orders of $100 or more within the 48 contiguous United States. Eligibility is calculated on the merchandise subtotal after discounts and before tax.

Most in-stock orders using standard shipping are processed within 1-5 business days, and most arrive 2-11 business days after they are placed. Backordered and special-order items may take longer. Expedited UPS Ground is available at checkout for an extra charge, including on orders that qualify for free standard shipping. See our Shipping Policy for details.

Returns & Exchanges

Need to return an item? We’re happy to help. Eligible items may be returned by requesting authorization within 35 days of delivery. Once approved, your return must reach us within 21 days.

Return eligibility

Items must be unused, in new condition, and include their original packaging and all accessories. Machines that use water cannot be returned once unboxed, unless defective upon arrival.

Shipping and refunds

For non-defective returns, customers cover return shipping. Original shipping charges are nonrefundable. If your order included free shipping, our actual outbound shipping cost will be deducted from your refund. Eligible returns have no restocking fee.

Received a defective item?

Contact us so we can help arrange a prepaid return label and replacement.

Please review our Return & Refund Policy for complete details and exclusions.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

Trovac Tangential Electro-M...

$188.99

Product details

This is a replacement tangential electro-motor built for 240V central vacuum power units, part FMCY034301, supplied with connection wires already attached so it drops into the wiring harness without splicing new leads. The motor's profile measures 3.2 in., which sets how much clearance it needs inside the canister.

A tangential motor draws air through the fan and discharges it off to one side of the housing rather than straight through the shaft, a layout used across central vacuum power units built to run quietly over long duty cycles. On the bench, a motor that has lost suction, developed a grinding bearing noise, or stopped starting altogether is usually past the point of repair and gets swapped rather than rebuilt.

  • Part: FMCY034301
  • Supplied with: connection wires
  • Voltage: 240V
  • Profile: 3.2 in.
  • Trovac lists it for: E105, GX7515PA, DL7515PA, HX7515PA, HD7515

Before ordering, check the motor already in your unit for the same 240V rating, the 3.2 in. profile, and a matching mounting pattern, since central vacuum power units are built around motors of several diameters and voltages. Trovac lists this motor for its E105, GX7515PA, DL7515PA, HX7515PA and HD7515 power units.
