Hayden SuperValve Direct Co...
$26.99
Product details
This Hayden SuperValve is a 110V side-opening direct connect wall inlet, compatible with Hayden and Canplas central vacuum equipment, finished in white. Direct connect means there is no external power cord to plug in separately: insert the hose into the inlet and the power nozzle switches on by itself, turning what is normally a two-step start into one.
The side-opening door sits flush with the wall and swings clear of the connection point when the hose goes in, which keeps the opening unobstructed during use. Because it wires directly into a 110V receptacle rather than routing through a low-voltage pigtail, it suits installations where a nearby outlet makes direct wiring the simpler path.
Replace an inlet valve when the door no longer closes flush, the receptacle connection has become unreliable, or an older inlet is being retrofitted to support direct connect operation. Confirm your system is Hayden or Canplas before ordering, since inlet mounting patterns vary across central vacuum brands and are not reliably interchangeable.
Because the receptacle wires directly into household power, have a qualified electrician handle the connection if you are not comfortable working inside a wall box with live circuits. Once wired, test the direct connect function with a hose before closing the wall plate, confirming the power nozzle activates promptly on insertion and shuts off cleanly on removal.
- Part: 792095W, Hayden SuperValve direct connect inlet
- Fits: Hayden or Canplas central vacuum equipment
- Finish: white, side-opening door, 110V receptacle
- Replace when: the door no longer seals flush or the receptacle connection is unreliable
