SEBO Suction Neck for AIRBE...
$31.00
Product details
SEBO opens the AIRBELT K parts drawing with the structure of the machine and works inward, which puts the suction neck at position 2 — with 6677GS the gray black moulding specified for the K3 PREMIUM.
The first few positions on that sheet follow the air rather than the assembly order, so they read almost as a diagram of the dirt path. Position 1 is bottom casing 6754GS with its castors, 2 is this neck, 3 the seal 6014 that closes it against the casing, 4 the spring lock 6042WS and 5 the bag holder 6681HG that carries an AeraPure bag. Ahead of the neck is the hose and handle assembly with dual controls, 8545AM. Everything the K3 picks up travels through this moulding before it reaches the bag.
Damage is easy to miss because there is nothing to see from outside the machine. A hairline split admits air without opening a visible gap, and the only symptom is a canister that quietly stopped lifting dirt the way it once did while sounding entirely healthy. That combination — normal noise, poor pickup, clean filters, part-full bag — points at a leak somewhere ahead of the bag, and the neck is the piece most worth checking before anyone starts condemning motors or buying hoses.
- Part number: 6677GS
- Fits: SEBO AIRBELT K3 PREMIUM
- Diagram position: item 2 on the AIRBELT K sheet
- Colour: gray black
- Seals against: bottom casing 6754GS, via seal 6014
- Related numbers: 6042WS spring lock, 6681HG bag holder, 6629AM filter bags, 8545AM hose and handle
- Replace when: the moulding shows cracks or splits, or the joint whistles when the machine runs
Necks are cut per machine and are not shared across the range, so order by number rather than by finish — gray black is simply how this one is moulded. The job itself is straightforward with the canister opened out on a bench and the bag removed. Factory SEBO neck, authorized dealer stock, sent out in 2–5 business days.
