Powr-Flite Backpack Vacuum ...
$90.99
Product details
Part X1296 is a complete backpack vacuum motor assembly, 1200W at 120 VAC, built around a Zeng Hsing Industrial motor.
Because it ships whole rather than as a bare motor, swapping it in replaces the fan, housing and mounting as one unit, leaving only the wiring connections at the terminals to redo.
Match this listing against whatever code is stamped directly on the motor you pull out, not by the look of the housing surrounding it, since several backpack platforms share nearly identical external housings while running different motors inside. Confirm the wattage and voltage rating on your old motor's data plate line up with this one before you order. Backpack motors run for hours at a stretch under continuous load, a harder duty cycle than almost any upright or canister sees in home use, and it is the main reason a commercial backpack motor eventually needs replacing well before the rest of the machine shows its age. A motor nearing the end of its life usually gives some warning before it quits outright: a change in pitch under load, a burning smell after a long run, or brushes that need replacing more often than they used to. Swapping in a fresh assembly at that point avoids a mid-shift failure on a route where downtime costs more than the part.
- Part: motor assembly, X1296
- Motor: Zeng Hsing Industrial
- Power: 1200W
- Supply: 120 VAC
- Installation: single-assembly swap, reconnect wiring terminals only
- Warning signs: pitch change under load, burning smell after long runs, frequent brush wear
Ships in 2-5 business days.
