Oreck

Oreck UK30200/UK30300 Circuit Board with Brush Roll Sensor

Oreck UK30200/UK30300 Circuit Board with Brush Roll Sensor

$18.99 USD
$18.99 USD
Sale Sold out
Shipping calculated at checkout.

430001004
Authorized Oreck Dealer Factory warranty, extended free where we can
Free Shipping On Eligible Orders $100+
Secure Checkout SSL Encrypted

Shipping Information

We offer free standard shipping on eligible orders of $100 or more within the 48 contiguous United States. Eligibility is calculated on the merchandise subtotal after discounts and before tax.

Most in-stock orders using standard shipping are processed within 1-5 business days, and most arrive 2-11 business days after they are placed. Backordered and special-order items may take longer. Expedited UPS Ground is available at checkout for an extra charge, including on orders that qualify for free standard shipping. See our Shipping Policy for details.

Returns & Exchanges

Need to return an item? We’re happy to help. Eligible items may be returned by requesting authorization within 35 days of delivery. Once approved, your return must reach us within 21 days.

Return eligibility

Items must be unused, in new condition, and include their original packaging and all accessories. Machines that use water cannot be returned once unboxed, unless defective upon arrival.

Shipping and refunds

For non-defective returns, customers cover return shipping. Original shipping charges are nonrefundable. If your order included free shipping, our actual outbound shipping cost will be deducted from your refund. Eligible returns have no restocking fee.

Received a defective item?

Contact us so we can help arrange a prepaid return label and replacement.

Please review our Return & Refund Policy for complete details and exclusions.

Warranty Information

All products sold by Vacuums and More come with the manufacturer's warranty. Warranty terms vary by brand and product.

With 35 years of industry experience, we stand behind every product we sell. Contact us for warranty support.

View full details

Oreck UK30200/UK30300 Circu...

$18.99

Product details

This is the circuit board with the Hall-effect brush roll sensor for the Oreck UK30200 and UK30300 uprights, part 430001004. The board runs the machine's electronics and watches the brush roll through a magnetic sensor, so it knows when the roller has stopped turning.

Boards fail in ways that look like other faults. The machine will not start, or it starts and shuts itself down again; the brush roll indicator stays lit with a perfectly good roller and belt fitted; the controls answer intermittently. Years of heat cycling crack solder joints, and a sensor that has drifted reads a turning roller as a stalled one.

Disconnect the machine from the mains before handling the board. Check the belt and roller first, though, since they cause the same symptoms far more often and cost far less to put right.
